Basic structure of a tensor

// ggml.h
struct ggml_tensor {
    enum ggml_type    type;  // e.g. GGML_TYPE_F32
    enum ggml_backend backend; // cpu or gpu

    int     n_dims; // ranges from 1 to 4
    // number of elements
    int64_t ne[GGML_MAX_DIMS];
    // stride in bytes
    size_t  nb[GGML_MAX_DIMS];

    enum ggml_op op; // either None or operations between tensors

    struct ggml_tensor * src[GGML_MAX_SRC]; // empty or points to src tensors for OP

    void * data; // tensor or null if tensor is an op

    char name[GGML_MAX_NAME];
};
  • ne contains the number of elements in each dimension. ggml is row-major order, e.g. for a 2x4 matrix A (2 rows, 4 columns), each row has 4 elements, thus ne[0] = 4 and ne[1] =2 (number of elements in a column)

    • This means that the fastest moving dimension is the “first one”, which is the opposite of the Pytorch notation where the last one is the fastest moving.
  • nb contains the stride: the number of bytes between consecutive elements in each dimension.

    • assuming float32, nb[0] = sizeof(float) = 4
    • Then, nb[1] = ne[0]*nb[0] (length of first dim in bytes)
    • We can then define bottom-up: nb[i]=ne[i-1]*nb[i-1]
      • (4,3,2) tensor

Tensors operations and views

  • op may be any supported operation between tensors. Setting it to GGML_OP_NONE marks that the tensor holds data. Other values can mark an operation. This is because ggml_tensors are part of a computation graph.

  • src is an array of pointers to the tensors between which the operation is to be taken. For example, if op == GGML_OP_MUL_MAT, then src will contain pointers to the two tensors to be multiplied. If op == GGML_OP_NONE, then src will be empty.

  • data points to the actual tensor’s data, or NULL if this tensor is an operation. It may also point to another tensor’s data, and then it’s known as a view e.g. ggml_transpose().

  • Matmul example (result does not contain any data. It just represents the theoretical result of multiplying a and b)

// ggml.c (simplified and commented)
struct ggml_tensor * ggml_mul_mat(
        struct ggml_context * ctx,
        struct ggml_tensor  * a,
        struct ggml_tensor  * b) {
    // Check that the tensors' dimensions permit matrix multiplication.
    GGML_ASSERT(ggml_can_mul_mat(a, b));

    // Set the new tensor's dimensions
    // according to matrix multiplication rules.
    const int64_t ne[4] = { a->ne[1], b->ne[1], b->ne[2], b->ne[3] };
    // Allocate a new ggml_tensor.
    // No data is actually allocated except the wrapper struct.
    struct ggml_tensor * result = ggml_new_tensor(ctx, GGML_TYPE_F32, MAX(a->n_dims, b->n_dims), ne);

    // Set the operation and sources.
    result->op   = GGML_OP_MUL_MAT;
    result->src[0] = a;
    result->src[1] = b;

    return result;
}

Computing tensors

  • The ggml_mul_mat() function above, or any other tensor operation, does not calculate anything but just prepares the tensors for the operation.
  • A different way to look at it is that it builds up a computation graph where each tensor operation is a node,
    • The operation’s sources are the node’s children.
    • In the matrix multiplication scenario, the graph has a parent node with operation GGML_OP_MUL_MAT, along with two children.
// llama.cpp
static struct ggml_cgraph * build_graph(/* ... */) {
    // ...

    // A,B are tensors initialized earlier
    struct ggml_tensor * AB = ggml_mul_mat(ctx0, A, B);

}

In order to actually compute the result tensor, the following steps are taken:

  1. Data is loaded into each leaf tensor’s data pointer. In the example the leaf tensors are A and B.
  2. The output tensor (AB) is converted to a computation graph using ggml_build_forward(). This function is relatively straightforward and orders the nodes in a depth-first order.1
  3. The computation graph is run using ggml_graph_compute(), which runs ggml_compute_forward() on each node in a depth-first order. ggml_compute_forward() does the heavy lifting of calculations. It performs the mathematical operation and fills the tensor’s data pointer with the result.
  4. At the end of this process, the output tensor’s data pointer points to the final result.
